5000 Series

TOMMA’s 5000 series is a high performance single wheel bottom sliding door roller manufactured with premium grade material & larger 36mm wheels to achieve a 25% reduction in operating force compared to other rollers available in the market. The 5000 series is made with precision double sealed bearings, to ensure effortless opening & a riveted inner carriage for premium strength. Built with a patented design allowing up to 10.0mm full adjustment under load. The 5000 series sliding door roller will allow you to smoothly operate doors up to 110kg, achieving an effortless operation synonymous with all TOMMA products.

• Download Brochure

• Tech Guide

Tomma 5000 Series sliding door roller

---

Features & Benefits

• Allows for easy adjustment

• Load capacity of up to 110kg doors

• Available in Zinc Plated or stainless steel

• Easily customised out carriage options

• 10 year guarantee

• Stainless Steel or Plastic Tyres

• Double sealed bearings

• Corrosion resistant

• Customisation for individual extrusions

5000 Series Inner Carriage Options

SNG is the standard Tomma Roller

SNG - Nylon Tyres & Stainless Steel Bearing (Coastal)
SND - Nylon Tyres & Zinc Bearing (Non Coastal)
SSG - Stainless Steel Tyre & Stainless Steel Bearing (Coastal)

---

SPECIFICATION DRAWINGS

• 45-5000-SNG

• 45-5001-SNG

• 45-5010-SNG
